Cue, Monitor, Talkback, Noise
TouchMix-16 & TouchMix-30 only
TouchMix-16 only
M
ain
O
utputs
L R
Cue
L R Aux (Odd) To Multi-Track FX Sub-Groups (odd) * Sub-Groups (even) * Aux (Even)
Phones
D/A
D/A
Monitor
Monitor
Level
Monitor Source *
-Aux
-Main L/R
-Cue
Monitor
Monitor Level
D/A
D/A
TouchMix-30 only
Talkback In
Main
Aux es
Enable Talk Level
FX
Noise Level
Noise
Generator
Enable
A/D
Phones Level
* TouchMix-30 only
To RTA &
Room Tuning*
D/A
D/A
Delay
Mic
Pre
+48 V *
