2-Trk Playback − Presets
Recall presets for the MP3 Stereo and the 2-Trk
Playback.
1. Presets tab – Selects the Presets screen.
2. Current Preset – Displays the name of
the currently active preset (if any).
3. Save / Save As button – Displays
a page with options for naming a scene and
selecting internal or USB storage destination.
4. Factory list – Displays a list of the factory
programmed presets available for the currently
loaded FX device. Touch a preset name to
select.
5. Mixer (internal) list – Displays a list
of presets that have been stored to mixer’s
internal memory.
6. USB (external) list – Displays a list of
presets that have been saved on an external
(USB) drive.
7. Delete button – Deletes a selected
preset from the mixer or USB user memory.
8. Copy to USB button – Copies the
selected preset to an external USB Drive.
9. Copy to Mixer button – Copies the
selected preset to the internal mixer memory.
10. Recall button – Recalls the playback
parameters of the selected preset. Recall
affects Aux Sends, EQ, Mutes, and Group
assignments.
11. Omit Levels – When on, the Aux and
2-Trk PB fader levels are not affected by the
preset Recall. EQ levels are affected by the
Recall in either position.
Press Rec/
Play
Touch
Recording
Mode
Touch Stereo
MP3
Touch
Presets
OR
Press Rec/
Play
Touch
Recording
Mode
Touch
Multitrack
USB Drive OR
Touch
Multitrack
DAW
Touch
Stereo
In / 2–Trk
Touch
2-Trk PB
Touch
Presets
Joe’s Monitor
Aux 1
Aux 2
Aux 2
Aux 3
Aux 3
Aux 4
Aux 4
Aux 5
Aux 5
Aux 6
Aux 6
Aux 7
Aux 7
Aux 8
Aux 8
Aux 9
Aux 9
Aux 10
Aux 10
Aux 11
Aux 11
Aux 12
Aux 12
Aux 13
Aux 13
Aux 14
Aux 14
Main Mix
L/R Default
Scene:
Overview Effect Auxes Setup EQ Presets
Prev Next
L
G
48
L
AF
∞ ∞
Cue
L C R
Playback
PB
10
5
u
5
10
20 0
40
10 10
5
u
5
10
20 0
40
10
2-Trk PB Main
Cue
Main
L/R
Mute Mute
Rec/
Play
Recording
Mode
Presets Stereo MP3
USB Drive Playback
2-Trk PB Rec/
Play
Recording
Mode
Presets Multitrack
USB Drive
OR Multitrack
DAW
Stereo In/2-Trk
2 3
5 6
1
8 9
11
7
4
10
7
