QSC Audio TouchMix-30 Pro 32-Channel Compact Digital Mixer with Touchscreen - Manual (Page 137)

128 1001108-01-F
M
ain
O
utputs
L R
Cue
L R Aux (Odd) To Multi-Track FX Sub-Groups (odd) * Sub-Groups (even) * Aux (Even) User EQ
Room
Tuning
Speaker
Preset
Main Fader From DCA Masters
Main Left
Main Right
Meter
* TouchMix-30 only
TouchMix-30 Only
RTA
Post
Aux. Level
(9 - 14)
SUM
To Mono Mode Auxes
To Stereo Mode Auxes (Odd/L)
To Stereo Mode Auxes (Odd/R)
Record
Pick-Off
Pre
Feedback
Wizard
2-Track Record
Level
From
TouchMix-30: Talkback In
TouchMix-16: In 16
TouchMix-8: In 8
Balance
Delay Low Cut High Cut Limiter Gain Gain GEQ Mute
Cue
GEQ
Room Tuning
Wizard
PEQ Anti
Feedback
D/A
D/A
SUM
Cue
Main Output
