Save Your Work as a Scene
You’ve put some effort into setting up your mix so now would be a great time to save it. A Scene is a snapshot of all the settings on the mixer.
TIP: It's a good idea to save your scene with the outputs muted or levels down. Why? Because it's possible that the gain settings
on power amplifiers or powered loudspeakers have changed since the scene was saved. Recalling the scene could result in a blast of
feedback from all the speakers connected to the mixer.
To Save Your Scene:
Menu
Scenes Save/Save As
To Name Your Scene:
Save Scene
As:
Saturday Night
To Save Your Scene:
Mixer USB
Storage Location
Save
Sound Check
Before connecting anything, plug in your TouchMix and make sure that all the inputs and Auxiliary Outputs are muted. This will prevent uncontrolled
feedback if a microphone is patched into a hot channel.
To Mute Channels:
Inputs 1-8 Inputs 9-16 Inputs 17-24 Stereo In/2-Trk Aux Masters Aux Out 9-14
Mute Mute Mute Mute Mute Mute Mute Mute Mute Mute Mute Mute
In each of the groups of faders, press the Mute button for each channel. Now you can connect the mixer to sources and speaker systems.
Using TouchMix with QSC Amplifiers and Loudspeakers
If you’re using QSC E , K , K.2 , KW or KLA loudspeakers or GXD amplifiers your TouchMix can recommended input level
settings to help optimize your system gain structure as well as offering output presets for different applications.
For Main L/R: Main Setup Select an amplifier or loudspeaker series.
For Aux outputs:
Aux Masters
Aux 1 Setup Select an amplifier or loudspeaker series.
Loudspeaker Nain and Preset Pop-up
In addition to displaying the recommended input gain setting (1) for the selected
loudspeaker (2), the pop-up displays a choice of presets (3) for the loudspeaker. For
most QSC loudspeaker there are options that optimize the loudspeaker for live sound
reinforcement, stage monitor use or dance music playback.
In the pop-up all you need to do is:
1. Touch the button associated with your loudspeaker, or amplifier
2. Adjust your equipment as instructed
3. Select the preset you want to use with your loudspeakers
4. Touch Recall Preset.
Recall Preset
0dB
GAIN
OFF +10dB
Rotate Gain knob 5 detents (clicks) past zero.
Select QSC Speaker Model and Preset Name to display Gain Settings or Recall a Preset
K10.2
K10.2
K12.2
K8.2
Preset Name Model
Studio
Dance
Floor Monitor
Live Bright
Live
Vocal Monitor
Done
3
1
2
