Record / Playback (Multitrack USB Drive)
Provides the controls to record and playback
multiple channels.
Record / Playback – Main Screen
TIMIOUCOUN!: All USB memory
devices must be formatted as FAT32.
Drive performance is critical for
recording. For more information and to
see a list of qualified drives, visit qsc.
com.
OIUT!: At the end of a session, the
recording must be stopped using the Stop/
Pause control. Stopping the recording
writes a header file that is required for the
tracks to play.
OIUT!: All the standard channel
controls act as they do regardless of
record / playback status. For example, if
you Mute the channel that is recording, the
output gets muted, but recording of the
input continues.
1. Input Channel controls – All input channel controls function as they do from the Home screen.
2. Arm – Arms the channel to be recorded when the Record button is pressed. Displays here and on the Home screen .
3. Track – When engaged, selects a recorded track as the audio source for the channel instead of the analog input.
4. USB Session – Displays the name of the active multi-track recording session.
5. Transport controls – Standard transport controls; Return to Start, Rewind, Play, Forward, Pause and Record.
6. Total record time counter – The total length of the recording in HH:MM:SS. If recording is in progress, this number grows
until the recording is ended.
7. Recording Mode – Displays a panel for selection of Stereo MP3, Multitrack or DAW (see the MP3 Audio Player and DAW topics).
8. Set – Moves the Locate pointer to the position of the Play pointer.
9. Go To – Moves the Play pointer to the position of the Locate pointer.
10. Play pointer – Indicates current record/playback position.
11. Locate pointer – Marks a location on the Time Line. The locate pointer may be moved by dragging on screen, by selecting and
turning the Master Encoder or using the Set button.
12. Progress indicator – Represents the session time line.
OIUT!: Due to FAT23 file size limitations, the max continuous recording time is roughly three hours. A warning message is
displayed 10 minutes before the limit is reached. To continue recording, pause and then resume. It is not necessary to create a new
session. (see “Recording Directory Structure” for more).
13. Time code display – Displays position of the Play pointer in HH:MM:SS. Maximum record time is determined by the capacity of
the attached hard-disc drive.
14. Recording Setup – Navigates to the Recording Setup screen.
Press
Rec/Play
Touch
Recording
Mode
Touch
Multitrack
USB Drive
Rec/
Play
Recording
Mode
Multitrack
USB Drive
