20 1001108-01-F
Copy & Paste
The TouchMix-30 Pro has a powerful but simple copy and paste function that is operated by the U7 (copy) and U8 (paste) buttons (U2 and U3 on
the TouchMix-8 and TouchMix-16). Copy and Paste is context sensitive so that what you are looking at is what will be copied. Only like things may
be copied and pasted from and to each other. For example, a PEQ cannot be pasted to a GEQ. The table below explains what parameters will be
copied and pasted.
NOTE: The copy buffer retains the last item of each type that has been copied. If, for example a GEQ setting is copied and then a
Gate is copied, both will reside in memory. If a GEQ is displayed, Paste will recall the copied GEQ parameters. If a Gate is displayed,
Gate parameters will be pasted.
To copy and paste parameters:
Aux Masters
Aux 1
U7
Copy
Aux 5
U8
Paste
The example above shows the mix that’s on Auxiliary 1 copied to Auxiliary 5.
After set-up is complete, it may be useful to clear the Copy/Paste buffer. This will prevent accidentally pasting parameters during the show. To clear
the Copy/Paste memory:
To clear the Copy/Paste buffer: Menu Clear Copy/Paste Yes
What’s Displayed What will be copied & pasted
Main or Auxiliary Faders View Fader and Pan
Input Channel Overview Tab EQ, Compressor, Gate, FX sends, Aux Sends, Digital Gain, Delay, Group
Assigns, Polarity
Input Channel EQ Tab All channel EQ parameters
Input Channel Comp Tab All channel Compressor parameters
Input Channel Gate Tab All channel Gate parameters
Input Channel FX Tab All channel FX send levels
Input Channel Aux Tab All channel Auxiliary Send levels and Pan positions
Input Channel Setup Tab Recording Arm, Polarity, Delay, Digital Gain, Group assignments
Output Channel Overview Tab PEQ, Limiter, FX sends, Aux Sends, Delay, Group Assigns, Polarity, Pick-
Off Point (Auxes only)
Output Channel PEQ Tab All channel PEQ parameters
Output Channel GEQ Tab All channel GEQ parameters
Output Channel Anti-Feedback Tab All channel Anti-feedback parameters
Output Channel Limiter Tab All channel Limiter parameters
Output Channel FX Tab All channel FX send levels
Output Channel Aux Tab All channel Auxiliary Send levels and Pan positions
Output Channel Setup Tab Recording Arm, Polarity, Delay, Digital Gain, Group assignments
FX Channel Overview Tab Current Preset, EQ, Pick-Off Point, Group Assigns, Polarity
FX Channel EQ Tab All FX channel EQ parameters
FX Channel Preset Tab Processor and Preset selection, FX Returns and Pans to Aux
FX Channel Aux Tab All FX Channel Auxiliary Send levels and Pan positions
Sub Group Overview Tab PEQ, Limiter, FX sends, Aux Sends, Group Assigns
Sub Group EQ Tab All Sub Group PEQ parameters
Sub Group Limiter Tab All Sub Group Limiter parameters
Sub Group FX Tab All Sub Group FX send levels
Sub Group Aux Tab All Sub Group Auxiliary Send levels and Pan positions
