This section explains how to load documents into the ADF.
Preparation
1
If you are loading multiple sheets, check the documents.
1 Check that the documents to be loaded are of the same width.
Documents that are different in width can not be loaded together at
a time.
2 Check the number of sheets.
Up to 50 sheets can be loaded (with paper weight of 80 g/m 2 [20 lb]
and thickness of the document stack under 5 mm).
For details, refer to
"Loading Capacity" (page 37) .
2
Fan the documents.
1 Grab a stack of documents, which should be 5 mm or less.
2 Hold both ends of the documents and fan them a few times.
3 Rotate the documents by 90 degrees and fan them in the same
manner.
4 Perform steps 1 to 3 for all documents.
5 Align the edges of the documents.
2.1 Loading Documents into the ADF
HINT
For details about the paper size and quality required for normal
operations, refer to
"2.3 Documents for Scanning" (page 35) .
HINT
For more details about how to fan documents, refer to the Error
Recovery Guide.
