How to Load Documents
1
Set the ADF paper chute (feeder).
For details, refer to "1.6 Setting Up the ADF Paper Chute (Feeder)"
(page 22) .
2
Lift up the stopper if needed.
For details, refer to "1.7 Setting Up the Stacker" (page 23) .
3
Load documents in the ADF paper chute (feeder).
Load the documents with the front side (scanning side) facing up.
4
Adjust the side guides to the width of the documents.
Do not leave space between the side guides and the documents.
Otherwise, the documents may be fed skewed.
5
Scan the documents with the image scanning application.
For details, refer to the image scanning application manual.
ATTENTION
 Remove all paper clips and staples.
 Reduce the number of sheets if a multifeed or pick error occurs.
ABC
Side Guides
