MOTLoad Commands
MOTLoad Firmware Package User’s Manual (6806800C24D)
86
3.1.31 errorDisplay
Name
errorDisplay—displays the MOTLoad test error status table (log). The error status table
contains test error information and task related information from previously executed tests
that failed and logged the failure information in the error log. Most of the fields in this table are
described below. The user can, through the -a option (in hexadecimal values), and the -n and -
s options, (in decimal values), specify which error log entry(ies) to display. In addition to the
information below, each error displays a unique test specific message.
Synopsis
errorDisplay [-a] [-n] [-s]
Parameters
-a P*: Executive Process/Task Identifier of Entry to Display
-n P*: Number of Entries to Display
-s P*: Specific Entry Number (1 to n) to Display
Field Name
Field Description
sPID
OS Process ID
ePID
Executive Process ID
eS.eM
Executive State.Executive Mode
entryNo
Test task entry number
sErrNo
OS Error number
eErrNo
Executive Error number
errCnt
Test Error count
loopCnt
Test Loop count
sTime
Test Start time
fTime
Test Finish time
eTime
Test Elapsed time
lTime
Time the error was logged
