5-3
5.3 Installing the servo amplifier
5 Installation
5.3 Installing the servo amplifier 5300 Installing the servo amplifier 5- Montage  Installation materials: 4 hexagon socket cylinder head screws
DIN 4762, M5
 Required tool: Hexagonal wrench 4 mm
Proceed as follows:
 Drill M5 holes in the control cabinet's mounting plate, as shown in the
illustrations.
 Attach the servo amplifier to the mounting plate in your control cabi-
net.
