3-3
3.1 Intended use
3 Safety
 Power supply protection:
 Only for use with fixed earthed Y-power supply or similar.
3.1.5 Safety function STO
Safety function STO 3- ][Sicherheit_Bestimmung_STO
The safety function "safe torque off" (Safe Torque Off, STO) activates
the pulse disabler on the servo amplifier and removes the power to the
motor. It meets the requirements in accordance with EN 61800-5-2.
The inputs STO1-ENABLE and STO2-ENABLE meet the following re-
quirements:
 With single-channel activation without feedback, in accordance with
EN ISO 13849-1: PL d (Cat. 2) and EN/IEC 62061: SIL CL 2.
 With dual-channel activation with feedback, in accordance with
EN ISO 13849-1: PL e (Cat. 4) and EN/IEC 62061: SIL CL 3.
The safety card PMCprotego S1 or PMCprotego S2 can also be used to
trigger the safety function STO.
The STO1-ENABLE input on the servo amplifier has no function if the
servo amplifier contains a safety card. In this case, the safety card acti-
vates the safe pulse disabler on the servo amplifier in order to shut down
the power element.
Unit Fuse class Nominal data Max. fuse rating
and short circuit
rating
PMCprotego
D.48 RK5, CC, J, T 600 VAC 60 A / 200 kA
PMCprotego
D.72 RK5, CC, J, T 600 VAC 80 A / 200 kA
NOTICE
With dual-channel activation of the inputs STO1-ENABLE and
STO2-ENABLE, the safe pulse disabler must be tested periodi-
cally to ensure it switches safely. See section 4.3.3, entitled
"Safety function STO".
