4.4 Expansion cards
4 Function Description
Setting the transmission rate
There are three ways to set the transmission rate.
 Use the rotary switch under “Baudrate” to set the transmission rate.
Switch setting Value Description
0
D
125 kBit/s
1
D
250 kBit/s
2
D
500 kBit/s
2
D
… 9
D
Example = 4
There are two options:
1.
You can set the transmission rate using
the terminal commands DNBAUD x,
SAVE, COLDSTART, where "x" stands
for 125, 250 or 500.
2.
You can set the transmission rate of
the DeviceNet object (Class 0x03, At-
tribute 2) to a value between 0 and 2.
You can use a DeviceNet commission-
ing tool to do this. You must save the
parameters in non-volatile memory
(Class 0x25, Attribute 0x65) and restart
the drive after changing the transmis-
sion rate.
