7.5 Messages/errors
7 Commissioning
Pilz GmbH & Co. KG, Felix-Wankel-Straße 2, 73760 Ostfildern, Germany
Telephone: +49 711 3409-0, Telefax: +49 711 3409-133, E-Mail: [email protected]
7-14
7.5 Messages/errors 7500 Messages/errors 7- 7.5.1 Status messages
Status messages 7- ][Inbetrieb_Meldung_Status
Status messages on the LED display indicate the operating status of the
servo amplifier.
7.5.2 Error messages
Error messages 7- ][Inbetrieb_Meldung_Fehler
Error are shown on the LED display with an error number. If an error oc-
curs, the BTB contact opens. The output stage of the servo amplifier
shuts down (motor is torque-free). The motor holding brake is activated.
No. Error message Description
E/S/
A/P Status messages Status message, no error
. . . Status message Amplifier updating the start configuration
- Status message Status message, no error, programming mode
- S - STO-ENABLE STO-ENABLE input = 0 V (if the drive is shut
down)
CCC SD card Problem when accessing the SD card
No. Error message Description
F01 Heatsink temperature Heatsink temperature too high (default: 80?)
F02 Overvoltage Overvoltage in the intermediate circuit. Limit
value depends on the mains voltage
F03 Drag error Message from the position controller
F04* Feedback Open circuit, short circuit, earth fault
F05 Undervoltage Undervoltage in the intermediate circuit (de-
fault: 100 V)
F06 Motor temperature Temperature sensor defective or motor tem-
perature too high
F07* Internal voltage Internal supply voltages faulty
F08* Overspeed Motor runs away, speed higher than permitted
F09* EEPROM Check sum error
F10 Reserved Reserved
F11* Motor brake Open circuit, short circuit, earth fault
F12 Motor phase Motor phase missing (open circuit or similar)
F13 Ambient temperature Ambient temperature too high
F14* Output stage Fault in the power output stage
F15 I²t max. I²t maximum value exceeded
F16 Mains BTB 2 or 3 infeed phases missing
