8-1
8.1 PMCprotego D.48
8 Technical Details
8 8000 Technical Details Technical Details 8- 8.1 PMCprotego D.48 8100 PMCprotego D.48 8- ][Technische Daten_protego_D
Technical details
Electrical data
Power element
Mains voltage AC
208 - 480 V
Voltage tolerance -10 %/+10 %
Power consumption in S1 mode 35.0 kVA
Frequency range AC 50 - 60 Hz
Max. switch-on frequency 30/h
Continuous output current at 3 x 400 VAC 48.0 A
Peak output current for 2 s 96.00 A
Peak output current for 5 s 96.00 A
Tolerance -3 %/+3 %
Clock frequency of inverted rectifier
in normal mode
8 kHz
Rated intermediate circuit voltage 290 - 675 V
Power dissipation at mains voltage 400 VAC
without brake
635 W
with inverted rectifier switched off 24 W
Brake chopper at mains voltage 400 VAC
Switch-on threshold for brake resistor
720 V
Shutdown at Overvoltage 800 V
External brake resistor R
Be
15 Ohm
Continuous output R
Be
6.0 kW
Pulse output R
Be
, max. 5 s 50.00 kW
Supply voltage 24 VDC
Supply voltage U
B
DC 24 VDC
Tolerance
with brake
+15 %
without brake +15 %
Max. current consumption
with brake
5.0 A
without brake 2.0 A
Current range, brake 0.15 - 3.00 A
Digital inputs
Number depends on the configuration
4 - 6
Input voltage 24 V DC
Signal level at "0" -3 - +5 V DC
Signal level at "1" 15 - 30 V DC
Input current at signal level "0" 1 mA
Input current at signal level "1" 2 - 15 mA
Scan rate DIGITAL-IN-1 and 2 500 kHz
Scan rate DIGITAL-IN-3 and 4 4 kHz
STO1-ENABLE, STO2-ENABLE
Number
1
Input voltage 20 - 30 V
Input current at signal level "1" 33 - 40 mA
Reaction time STO1-ENABLE 5 ms
Reaction time STO2-ENABLE 5 ms
