3-1
3.1 Intended use
3 Safety
3 3000 Safety Safety 3- 3.1 Intended use 3100 Intended use 3- ][Sicherheit_Bestimmung_protego_D
The servo amplifiers PMCprotego D are designed to drive suitable
brushless, synchronous servo motors and asynchronous motors with
closed loop speed, torque and/or position control.
][Sicherheit_Bestimmung_Ausschluss
The following is deemed improper use:
 Any component, technical or electrical modification to the servo am-
plifier
 Use of the servo amplifier outside the areas described in this manual
 Use of the servo amplifier outside the documented technical details
(see chapter entitled “Technical Details”)
Intended use includes making the installation and wiring EMC-compli-
ant. Please refer to the guidelines stated in this manual.
3.1.1 Hazard analysis
Hazard analysis 3- ][Sicherheit_Bestimmung_Gefahrenanalyse
The machine manufacturer must produce a hazard analysis for the ma-
chine. He must take appropriate measures to ensure that unexpected
movements do not lead to hazardous situations for either people or
equipment.
3.1.2 Electrical data
Electrical data 3- ][Sicherheit_Bestimmung_elektrisch_protego_D
Please note the electrical requirements stated in the chapters entitled
“Technical Details”, “Wiring” and “Function Description”.
][Funktion_Netzspannung_Drossel
INFORMATION
A 3L line choke with u
k
= 2% must be used in the event of a
mains voltage imbalance of > 3%. Install the line choke on the
mounting plate in a way that is EMC-compliant.
