Note: Make sure to define valid IN and OUT points for the left eye clip, otherwise you will not be
able to complete the following steps.
• You must define a “Sync Point” by entering a value for each clip (right and left eye) in the
timecode box (see Figure 38). After you have chosen the timecode values for each clip,
click “Set Sync Point.” The settings for the Duration and IN/Out points for the “Right Eye
Clip” will be automatically computed after the Sync Point is defined.
• After having defined the “Sync Point,” the duration values for the Left and Right eye
should match.
• Enter a Name and Clip ID (see Figure 38) for the new 3D file and click “OK.
3.2.7.3 3D Split
NOTE: This feature is enabled only when using a compressed V1 unit (“V1 JPEG 2000”).
The 3D split feature allows you to create a database clip for each one of the “eye” streams (left
and right) of a 3D file.
How to Split a 3D file:
• Select the 3D clip you want to split and click on the “3D Split” button;
• Click on Finish to start the “splitting process”
• When you are done, you will see the left and right eye streams under the “Clip
Database” window. The file name will be the same as the original with an extension of
“..._left” and “..._right.”
Figure 39: 3D Clip Splitting
