Inspecting the package

Before unpacking the 1783 NCT, inspect the carton for physical damage. If the exterior
package is damaged, contact your local sales office or distributor. Also contact the carrier
to request examination of the damage. The carrier is required to complete and sign a
damage report form. If the package is not damaged, remove the package contents which
includes a logic unit, a mouse, an AC power cable, and this user’s guide.

Setting up the 1783 NCT

To set up the 1783 NCT, refer to the diagram on the back of the logic unit and follow the
steps below:

CAUTION: The 1783 NCT has been designed to support the weight of 17-inch or smaller
display units. Display units larger than 17 inches MUST be placed beside the logic unit,
rather than on top.

1. Place the display unit on top (or beside) of the logic unit and position both within

connecting distance of an appropriate AC power outlet.

2. Make sure that the Power-On/Off switch is set to

O

(Off) on both the logic unit and

the display unit.

3. Place the keyboard in front of the logic unit. Pull out the feet underneath the keyboard

to adjust it to a higher setting, if desired. Insert the keyboard plug into the keyboard
connector on the back of the logic unit.

4. Refer to the owner’s manual that comes with your display unit for instructions on

how to attach the display unit’s data cable to the logic unit.

5. Plug the display unit’s AC power cable into an appropriate AC power outlet.

6. For the local screen print function, a printer connector is located on the back of the

logic unit. Attach the printer cable (provided with the printer) to the printer connector
on the back of the logic unit.

7. Insert the mouse’s cable connector into the mouse receptacle on the rear of the logic

unit. Check to ensure that the connector is firmly seated.

8. Plug one end of the power cable into the AC connector on the back of the logic unit.

Plug the other end of the AC power cable into the wall receptacle.
