1-8
Section 1 Ñ System Overview
Model 1200 System Specifications
Model 1200 specifications are listed in Table 1-1. The specifications for the
Model 1200 are subject to change without notice.
Table 1-1. Model 1200 System SpeciÞcations
Parameter Value
Environmental Characteristics
Operating Ambient Temperature
Range 0 - 40
°
C (32 - 104
°
F)
Ambient Temperature for
Specifications 20 - 30 ° C (68 - 86 ° F)
Relative Humidity 95% Maximum (Non-Condensing)
Frame Mechanical SpeciÞcations
Depth 24.8 inches (630 mm)
Width Std 19 inches (483 mm)
Height 10.25 inches (260 mm)
Rack Units 6
Weight 80 lbs. (36.3 kg)
Control Panel Mechanical SpeciÞcations
Depth 17.42 inches (443 mm)
Width 29.00 inches (260 mm)
Height 10.66 inches (260 mm)
Weight 48 lbs. (21.8 kg)
Frame Power SpeciÞcations
Power 400 Watts Maximum 99PFC
Voltage 100-240 VAC autoranging
Frequency 50-60 Hz
