Section 2 Ñ Installation
5. Press the
[Confg]
button on the main subpanel and then the
[OUTPUTS>]
soft button to display the Outputs menu. Use the
[SIGNAL SOURCE]
soft
button to select whether you want the Analog Output to provide a
Program Output or a Program Clean Feed Output. If the Analog
Output is mounted on the Preview Mixer, the choices are Preview
Output or Preview Clean Feed Output. (Clean feed video consists of
Program or Preview video without the downstream key.)
Table 2-1. Analog Output Option Jumper Settings
Format
Selection
J7
Analog Output
Support
Setup
J5, J6, J9, J11
Analog Output
Format
J4 (Y)
Analog
Output
Format
J8 (R-Y)
Analog
Output
Format
J10 (B-Y)
Analog
Output
Format
EBU/SMPTE
No Setup
a
a
b
c
RGB .714 v
No Setup
b
b
b & d
b & d
RGB .714 v
Setup
b
c
d
a & d
RGB .700 v
No Setup
b
a
a & d
b & d
MII 50 Hz
No Setup
a
a
c
c
MII 60 Hz
No Setup
a
a
c
e
MII 60 Hz
Setup
a
c
c
e
Beta 50 Hz
No Setup
a
a
d
d
Beta 60 Hz
No Setup
a
b
d
d
Beta 60 Hz
Setup
a
c
d
d
