2-19
System Setup
System Setup
The following procedures allow you to configure the 1200 system to your
installation. Using the Configuration menus in the menu display, you can
assign sources to the crosspoints, configure the inputs, set output levels,
adjust system timing, and set other system parameters. These menu items
are accessed through the Configuration menu (Figure 2-12) on the Menu
Display subpanel.
Figure 2-12. 1200 Configuration Menu Tree
Menu Pushbuttons and Knobs
The display panel includes pushbuttons and knobs that work interactively
with the display menus to control the switcher:
■ The white menu Òhot buttonsÓ at the left of the display activate the top
level menus.
■ The black buttons and knobs surrounding the display are ÒsoftÓ
buttons and knobs that change function with each menu. Labels
displayed along the bottom and right edges of each menu indicate the
functions of the soft controls. The Ò>Ó display symbol indicates a lower
level menu that you can view when you press the associated soft
button.
■ The [EXIT] button takes you up one menu level.
CONFG
System Params
Define Inputs
Crosspoints
Outputs
Timing
Ports
GPI
Tally
4:3/16:9, Edit Field Dom, System Clock
Define Inputs, Select CK Source, Xpt Legends
Configure Outputs
Switcher Timing Adjustment
Serial Port Configuration
GPI Setup
Tally Relay Output Monitoring and Testing
Map Inputs to Crosspoints
