2-8
Section 2 Ñ Installation
Cable Connections
Refer to Figure 2-5 and Figure 2-6 while following the instructions on
page 2Ð10 through page 2Ð14, which explains how to cable the required
connections for a Model 1200.
Figure 2-5. Model 1200 Frame Backplane
INPUT 1 J1 INPUT 2 J2 INPUT 3 J3
INPUT 5 J5 INPUT 6 J6 INPUT 7 J7
INPUT 9 J9 INPUT 10 J10 INPUT 11 J11
INPUT 13 J13 INPUT 14 J14 INPUT 15 J15
AUX OUT 1 J17 AUX OUT 2 J18 PGM OUT 1 J19
CLEAN FEED J21 PVW OUT J22 PGM OUT 2 J23
PARALLEL INPUT MODULE
O
U
T
P
U
T
S
I
N
P
U
T
S
SERIAL IN
SERIAL OUTPUT MODULE
PARALLEL INPUT MODULE PARALLEL IN
PARALLEL IN
PARALLEL IN PARALLEL INPUT MODULE
PARALLEL INPUT MODULE
PARALLEL OUT PARALLEL OUTPUT MODULE
SERIAL OUT
Serial and Parallel Component Digital Inputs 1-16
CCIR601 4:2:2 525 or 625 lines
Aux Bus 1 and 2
and Effects Send
Component Digital Outputs
Preview Video
Component Digital Output
Clean Feed Video
(Program without DSK)
Component Digital Output
Program Video
Component Digital
Outputs
