1-10
Section 1 Ñ System Overview
Analog CAV Output Characteristics
Number Of Outputs 1 PGM, 1 PVW (both optional)
Luminance 1.0 Volt pp with sync
Color Difference 350 mV pp bipolar
DC On Output Blanking Level < 50 mV
Output Return Loss > 40 dB to 5 MHz
Output Y/C Timing Error < 10 ns
Number Of Outputs 3
Number Of Outputs 1 PGM, 1 PVW (both optional)
Parallel Digital Output Characteristics
Number Of Outputs Per Module 2
Connector 25 Pin Female D Type with Screw Locks.
Output Impedance 110 ohms ± 10%
Output Amplitude 800 mV pp, terminated
DC Level On Output < 50 mV
Number Of Bits 8 or 10 bits (Selectable)
Maximum Cable Length 15 meters (50 feet)
Auxiliary Data Auxiliary data is blanked
Table 1-1. Model 1200 System SpeciÞcations - (continued)
Parameter Value
