Section 3 Ñ Functional Description
Frame Modules
Power Supply
The frame Power Supply Module is a switching power supply that
generates the following voltages:
The input voltage can be 100 to 240 Volts, 50 to 60 cycles. The power supply
is autoranging and power factor corrected.
The power supply along with the fan is enclosed in a removable sled to
make it easy to exchange broken power supples. The power supply is not
designed to be user serviceable.
The Control Panel has a separate Power Supply, refer to the Control Panel
section titled, Power Supply on page 3Ð10.
Table 3-1. Power Supply Module
Voltage Current Use
+5 Volts 60 Amps Frame, I/O Modules
-5.2 Volts 12 Amps I/O Modules
+9 Volts 1 Amp not used with Model 1200
+15 Volts 2 Amp not used with Model 1200
+12 Volts 0.5 Amps Fan
