User’s Manual of WGSW-5242
24
1.5 Product Specification
Product
WGSW-5242
48-Port 10/100Mbps + 4 Gigabit TP / 2 SFP Managed Switch
Hardware Specification
Copper Ports
48 10/100Base-TX + 4 10/ 100/1000Base-T RJ-45 Auto-MDI/MDI-X ports
SFP / mini-GBIC slots
2 100/1000Base-X SFP interfaces, shared with Port-51 and Port-52
Switch Architecture
Store-and-Forward
Switch Fabric
17.6Gbps / non-blocking
Switch throughput
13.09Mpps
Address Table
8K MAC address table with Auto learning function
Share data Buffer
4Mbits
Flow Control
Back pressure for Half-Duplex
IEEE 802.3x Pause Frame for Full-Duplex
LED
Power, Link/Act per port
Reset Button
< 5 sec: System reboot
> 10 sec: Factory Default
Dimension (W x D x H)
430 x 250x 44.5 mm, 1U height
Weight
2672g
Power Consumption
27.8 Watts / 110.70 BTU (Maximum)
Power Requirement
AC 100~240V, 50/60Hz ,2.2A (Maximum)
Layer Function
Management Interface
Console, Telnet, SSH, Web Browser, SSL, SNMPv1, v2c and v3
Port configuration
Port disable / enable
Auto-Negotiation 10/100/1000Mbps full and half duplex mode selection
Flow Control disable / enable
Port Status
Display each port’s speed duplex mode, link status, Flow control status, Auto negotiation status
VLAN
IEEE 802.1Q Tag-Based VLAN
GVRP for VLAN Management
Up to 256 VLANs groups, out of 4049 VLAN IDs
Private VLAN Edge (PVE) supported
Bandwidth Control
Ingress Rate Limit
Egress Traffic Shaper
Link Aggregation
IEEE 802.3ad LACP
Supports 6 groups of 8-Port trunk
QoS
Traffic classification based on 802.1p priority, IP TOS / DSCP / IP Precedence
IGMP Snooping
IGMP (v1/v2) Snooping, IGMP Querier mode
Access Control List
IP-Based ACL / MAC-Based ACL
Up to 128 entries
