User’s Manual of WGSW-5242
64
The page includes the following fields:
Object Description
• PVID The port default VLAN ID (PVID) is configured on the VLAN Port screen. All
untagged packets arrive to the device are tagged by the ports PVID.
• Protected Port When the ports specified as 'Protected Port', they can not forward traffic to each
other. Only the ports that are not specified as 'Protected Port' can forward traffic
to and from the protected ports respectively.
• Drop Non 1Q Frame When enabled, any Non-1Q ingress frame will be dropped by this port.
4.4.6 GVRP
When Switch GVRP is enabled, you can modify the GVRP settings of multiple ports.
But if it's disabled, GVRP will be disabled on all ports.
Click the Modify hyperlink to modify the GVRP settings of multiple ports when Switch GVRP is enabled.
On the port GVRP modification page, you can enable/disable GVRP on the port you specified.
