Studio Display
073-00335-A | 72
© 2022 Apple Inc. All rights reserved.
USB-C Boards | Removal
Removal
1. Use the T3 screwdriver to
remove the four T3 screws
(923-05561) from the
USB-C board connector
cowlings. Then remove the
two cowlings and save them
for reassembly.
2. Use the black stick to lift the
ends of the two flex cables
off the connectors.
Ensure that the support wedge is between the housing and the stand to keep the display in place.
Important
