Button Configuration Window Overview 45
All rights are reserved.
When you scan by the Grayscale Mode , you may click button for white edge fill or
button for black edge fill.
When you scan by the BW mode , you may click button for white edge fill or
button for black edge fill.
Tick the check box of All sides match , the widths of four sides would be set to be
the same. You may adjust the width by clicking buttons. If you do not tick this
check box, then you can adjust the width of each side individually.
Preview
By clicking on the Preview button, you can scan the source document into the
preview window within MacAction interface. Documents or images that are
previewed will be displayed here. The previewed image gives you an idea of how
a document or image will look after it is scanned.
Default
Clicking the Default button on the lower right corner revert the settings to its original
values and discard all adjustments you have made.
2.10 File Format Configuration dialog box
Within the Button Configuration window click the File , Scan , FTP or E-Mail icon on
the left pane and then click in the right pane, which opens this dialog
box.
The items and parameters available in the window are explained as follows:
