Grass Valley Maestro Master Control v.1.7 User Manual
Page 228
224
Maestro — Channel Branding User Guide
Appendix A — Animation File Size
NTSC 4x3 Full-Screen
3-Frame Animation Playout
PAL 4x3 Full-Screen
PAL 3-Frame Animation Playout
Table 4. NTSC 4x3 Full-Screen Information
Width
(pixels)
Height
(lines)
Aspect
Frame
Rate
(fr/sec)
Calculated
.mii
File Size
(mbytes)
Calculated
RAM
Buffer Size
(mbytes)
Max
Number Of
Cells
Stored
Est Length
In
Seconds
720
480
4:3
29.97
1.04
1.0368
169
5.63
Table 5. 3-Frame Animation Playout Information
Width
(pixels)
Height
(lines)
Aspect
Frame
Rate
(fr/sec)
Calculated
.mii
File Size
(mbytes)
Calculated
RAM
Buffer Size
(mbytes)
Max
Number Of
Cells
Stored
Est Length
In
Seconds
720
480
4:3
9.99
1.04
1.0368
169
16.90
Table 6. PAL 4x3 Full-Screen Information
Width
(pixels)
Height
(lines)
Aspect
Frame
Rate
(fr/sec)
Calculated
.mii
File Size
(mbytes)
Calculated
RAM
Buffer Size
(mbytes)
Max
Number Of
Cells
Stored
Est Length
In
Seconds
720
575
4:3
25
1.242
1.242
141
5.64
Table 7. PAL 3-Frame Animation Playout Information
Width
(pixels)
Height
(lines)
Aspect
Frame
Rate
(fr/sec)
Calculated
.mii
File Size
(mbytes)
Calculated
RAM
Buffer Size
(mbytes)
Max
Number Of
Cells
Stored
Est Length
In
Seconds
720
575
4:3
8.33
1.242
1.242
141
16.91
