TroubleshooTing and sysTem TesTs

powermax

65/85

Service Manual

5-25

Fault

code

Description

(System test number)

Power

LED

Fault

LED

Fault

icon

Solutions

0-30-0 Torch stuck open (Test 6)

The nozzle and electrode are

not touching after a start is

received.

On

On

• If incorrect consumables are installed or

the consumables became loose or were

removed while the power supply is ON, turn

OFF the power supply, correct the problem

and then turn ON the power supply to clear

this fault.

• Inspect the torch for signs of wet or oily air.
• Inspect the torch for any signs of damage or

pitting on the electrode contact surface.

• If the consumables appear to be installed

correctly, the torch may be damaged. Test

with a known working torch.

• For a 0-30-1 fault code, place the unit in gas

test mode (refer to page 5-21 Displaying

the service screen). Enter “manual mode”,

move to “G” (gas), and use the adjustment

knob to toggle to “1” (gas test mode).

Ensure that only the dump valve light is on

during the gas test. Toggle back to “0” and

exit “manual mode.” Replace the regulator if

necessary.

• If the problem persists, contact your

Hypertherm distributor or authorized repair

facility.

0-30-1 Torch stuck closed (Test 6)

• The nozzle and electrode

will not separate after a

start is received.

• The regulator may not be

functioning properly.

0-40-0 PFC/Boost IGBT module

under temperature (Test 4)

On

On

For an over-temperature fault, leave the

machine powered ON and confirm that the fan

is operating (Test 11). Ensure adequate air

flow around the unit.
Ensure the cover is placed with the air fins on

the fan side of the power supply.
If the duty cycle has been exceeded, let the

unit cool and work within the duty cycle limits

listed in the Operation section.
For an under-temperature (<-22°F or -30°C)

fault, move the unit to a warmer location.
The inverter temperature sensor is a thermistor

mounted on the heat sink beside the inverter

IGBT module. Its room temperature resistance

is about 10 kΩ.

0-40-1 PFC/Boost IGBT module

over temperature (Test 4)

0-40-2 Inverter IGBT module under

temperature (Test 4)

0-40-3 Inverter IGBT module over

temperature (Test 4)
