User’s Manual of SGSW-24040 / 24240 Series
118
For LLAG the id is shown as 'isid:aggr-id' and for GLAGs as 'aggr-id'
•
Partner System ID The system ID (MAC address) of the aggregation partner.
•
Partner Key The Key that the partner has assigned to this aggregation ID.
•
Last changed The time since this aggregation changed.
•
Local Ports Shows which ports are a part of this aggregation for this switch/stack.
The format is: "Switch ID:Port".
Buttons
: Click to refresh the page immediately.
Auto-refresh : Check this box to enable an automatic refresh of the page at regular intervals.
4.5.4 LACP Port Status
This page provides a status overview for LACP status for all ports. The LACP Port Status screen in Figure 4-5-6 appears.
Figure 4-5-6 LACP Port Status page screenshot
