User’s Manual of SGSW-24040 / 24240 Series
129
•
Accept Frame Type Determines whether the port accepts all frames or only tagged frames. This
parameter affects VLAN ingress processing. If the port only accepts tagged
frames, untagged frames received on the port are discarded. By default, the field
is set to All.
•
Link Type Allow 802.1Q Untagged or Tagged VLAN for selected port.
When adding a VLAN to selected port, it tells the switch whether to keep or
remove the tag from a frame on egress.
- Untag: outgoing frames without VLAN-Tagged.
- Tagged: outgoing frames with VLAN-Tagged.
• Q-in-Q Mode
Sets the Managed Switch to QinQ mode, and allows the QinQ tunnel port to be
configured. The default is for the Managed Switch to function in Disable mode.
- Disable: The port operates in its normal VLAN mode. (This is the default.)
- MAN Port: Configures IEEE 802.1Q tunneling (QinQ) for an uplink port to
another device within the service provider network.
- Customer Port: Configures IEEE 802.1Q tunneling (QinQ) for a client access
port to segregate and preserve customer VLAN IDs for traffic crossing the
service provider network.
Set Out layer VLAN tag
ether type
The Tag Protocol Identifier (TPID) specifies the ethertype of incoming packets on
a tunnel access port.
- 802.1Q Tag: 8100
- vMAN Tag: 88A8
Default : 802.1Q Tag
The port must be a member of the same VLAN as the Port VLAN ID.
Buttons
: Click to save changes.
: Click to undo any changes made locally and revert to previously saved values.
