User’s Manual of SGSW-24040 / 24240 Series
236
mesRx received by the switch.
Rx Logoff dot1xAuthEapolLogoffFr
amesRx
The number of valid EAPOL
Logoff frames that have
been received by the switch.
Rx Invalid Type dot1xAuthInvalidEapolF
ramesRx
The number of EAPOL
frames that have been
received by the switch in
which the frame type is not
recognized.
Rx Invalid Length dot1xAuthEapLengthErr
orFramesRx
The number of EAPOL
frames that have been
received by the switch in
which the Packet Body
Length field is invalid.
Tx Total dot1xAuthEapolFrames
Tx
The number of EAPOL
frames of any type that have
been transmitted by the
switch.
Tx Request ID dot1xAuthEapolReqIdFr
amesTx
The number of EAPOL
Request Identity frames that
have been transmitted by
the switch.
Tx Requests dot1xAuthEapolReqFra
mesTx
The number of valid EAPOL
Request frames (other than
Request Identity frames)
that have been transmitted
by the switch.
• Backend Server
Counters
These backend (RADIUS) frame counters are available for the following administrative
states:
Port-based 802.1X
Single 802.1X
Multi 802.1X
MAC-based Auth.
Direction Name IEEE Name Description
