User’s Manual of SGSW-24040 / 24240 Series
196
The page includes the following fields:
Object Description
•
Port The logical port for the settings contained in the same row.
•
Low Queue There are 4 QoS queues per port with strict or weighted queuing scheduling. This
is the lowest priority queue.
•
Normal Queue This is the normal priority queue of the 4 QoS queues. It has higher priority than
the "Low Queue".
•
Medium Queue This is the medium priority queue of the 4 QoS queues. It has higher priority than
the "Normal Queue".
•
High Queue This is the highest priority queue of the 4 QoS queues.
• Receive/Transmit
The number of received and transmitted packets per port.
Buttons
: Click to refresh the page immediately.
: Clears the counters for all ports.
Auto-refresh : Check this box to enable an automatic refresh of the page at regular intervals.
4.9.8 DSCP Remarking
This page allows you to configure DSCP remarking related settings for each port.
Frames can be classified by 4 different QoS classes: Low, Normal, Medium, and High.
The classification can be controlled by Port QoS configuration page.
And this page is used to configure DSCP remarking.
The DSCP value of incoming frames will be changed according to its mapping queue once this packet is transmitted by the
egress port. The DSCP Remarking Configuration screen in Figure 4-9-13 appears.
