User’s Manual of SGSW-24040 / 24240 Series
303
Local Counters
The displayed table contains a row for each port. The columns hold the following information:
Object Description
•
Local Port The port on which LLDP frames are received or transmitted.
•
Tx Frames The number of LLDP frames transmitted on the port.
•
Rx Frames The number of LLDP frames received on the port.
•
Rx Errors The number of received LLDP frames containing some kind of error.
•
Frames Discarded If an LLDP frame is received on a port, and the switch's internal table has run full,
the LLDP frame is counted and discarded. This situation is known as "Too Many
Neighbors" in the LLDP standard. LLDP frames require a new entry in the table
when the Chassis ID or Remote Port ID is not already contained within the table.
Entries are removed from the table when a given port links down, an LLDP
shutdown frame is received, or when the entry ages out.
• TLVs Discarded
Each LLDP frame can contain multiple pieces of information, known as TLVs
(TLV is short for "Type Length Value"). If a TLV is malformed, it is counted and
discarded.
• TLVs Unrecognized
The number of well-formed TLVs, but with an unknown type value.
• Org. Discarded
The number of organizationally TLVs received.
• Age-Outs
Each LLDP frame contains information about how long time the LLDP
information is valid (age-out time). If no new LLDP frame is received within the
age out time, the LLDP information is removed, and the Age-Out counter is
incremented.
Buttons
: Click to refresh the page immediately.
: Clears the local counters. All counters (including global counters) are cleared upon reboot.
Auto-refresh : Check this box to enable an automatic refresh of the page at regular intervals.
