User’s Manual of SGSW-24040 / 24240 Series
277
Configuration
• Port Mode
Configuration
Specify ARP Inspection is enabled on which ports. Only when both Global Mode
and Port Mode on a given port are enabled, ARP Inspection is enabled on this
given port.
Buttons
: Click to save changes.
: Click to undo any changes made locally and revert to previously saved values.
4.12.13 ARP Inspection Static Table
This page provides Static ARP Inspection Table. The Static ARP Inspection Table screen in Figure 4-12-13 appears.
Figure 4-12-13 Static ARP Inspection Table screen page screenshot
The page includes the following fields:
Object Description
• Delete
Check to delete the entry. It will be deleted during the next save.
• Port
The logical port for the settings.
• VLAN ID
The VLAN ID for the settings.
• MAC Address
Allowed Source MAC address in ARP request packets.
• IP Address
Allowed Source IP address in ARP request packets.
Buttons
: Click to add a new entry.
