User’s Manual of SGSW-24040 / 24240 Series
94
allowed string length is 0 to 255, and the allowed content is the ASCII characters
from 33 to 126.
•
Trap Destination
Address
Indicates the SNMP trap destination address.
• Trap Destination IPv6
Address
Provide the trap destination IPv6 address of this switch. IPv6 address is in
128-bit records represented as eight fields of up to four hexadecimal digits with a
colon separates each field (:). For example, 'fe80::215:c5ff:fe03:4dc7'. The
symbol '::' is a special syntax that can be used as a shorthand way of
representing multiple 16-bit groups of contiguous zeros; but it can only appear
once. It also used a following legally IPv4 address. For example, '::192.1.2.34'.
•
Trap Authentication
Failure
Indicates the SNMP entity is permitted to generate authentication failure traps.
Possible modes are:
Enabled: Enable SNMP trap authentication failure.
Disabled: Disable SNMP trap authentication failure.
• Trap Link-up and
Link-down
Indicates the SNMP trap link-up and link-down mode operation. Possible modes
are:
Enabled: Enable SNMP trap link-up and link-down mode operation.
Disabled: Disable SNMP trap link-up and link-down mode operation.
• Trap Inform Mode
Indicates the SNMP trap inform mode operation. Possible modes are:
Enabled: Enable SNMP trap inform mode operation.
Disabled: Disable SNMP trap inform mode operation.
• Trap Inform Timeout
(seconds)
Indicates the SNMP trap inform timeout. The allowed range is 0 to 2147.
• Trap Inform Retry
Times
Indicates the SNMP trap inform retry times. The allowed range is 0 to 255.
Buttons
: Click to save changes.
: Click to undo any changes made locally and revert to previously saved values.
