User’s Manual of SGSW-24040 / 24240 Series
233
4.11.4 Network Access Overview
This page provides an overview of the current NAS port states for the selected switch. The Network Access Overview screen in
Figure 4-11-5 appears.
Figure 4-11-5 Network Access Overview page screenshot
The page includes the following fields:
Object Description
• Port
The switch port number. Click to navigate to detailed NAS statistics for this port.
• Admin State The port's current administrative state. Refer to NAS Admin State for a
description of possible values.
• Port State
The current state of the port. Refer to NAS Port State for a description of the
individual states.
• Last Source
The source MAC address carried in the most recently received EAPOL frame for
EAPOL-based authentication, and the most recently received frame from a new
