User’s Manual of SGSW-24040 / 24240 Series
371
Parameters:
<port_list>: Port list or 'all', default: All ports
<vid>|none : Port VLAN ID (1-4095) or 'none',
(default: Show port VLAN ID)
Default Setting:
1
Example:
Set PVID2 for port20
SWITCH/>vlan pvid 20 2
VLAN Frame Type
Description:
Set or show the port VLAN frame type.
Syntax:
VLAN FrameType [<port_list>] [all|tagged]
Parameters:
<port_list>: Port list or 'all', default: All ports
all : Allow tagged and untagged frames
tagged : Allow tagged frames only
(default: Show accepted frame types)
Default Setting:
All
Example:
Set port20 that allow tagged frames only
SWITCH/>vlan frametype 20 tagged
VLAN Ingress Filter
Description:
Set or show the port VLAN ingress filter.
