User’s Manual of SGSW-24040 / 24240 Series
316
power limit value
Buttons
: Click to save changes.
: Click to undo any changes made locally and revert to previously saved values.
Only SGSW-24040HP has IEEE 802.3at mode and supplies max. power up to 30.8 watts.
4.16.4 PoE Status
This page allows the user to inspect the total power consumption, total power reserved and current status for all PoE ports. The
screen in Figure 4-16-3 appears.
