177
Product Specifications
O
ther Information
Pro
duct S
pecifica
tio
ns
Supported Signal Types
The projector automatically projects input signals correctly from computers or AV
equipment compatible with any of these signals.
HDMI (single)
Signal
resolution
Horizontal
frequency
[kHz]
Vertical
frequency
[Hz]
Dot clock
[MHz]
HDMI multi input
mode
Blanking information
Horizontal
FP, SW, BP
Vertical
FP, SW, BP
640x480 31.469 59.940 25.175 Normal, Single 16, 96, 48 10, 2, 33
720x480 31.469 59.940 27.000 Normal, Single 16, 62, 60 9, 6, 30
720x576 31.250 50.000 27.000 Normal, Single 12, 64, 68 5, 5, 39
800x600 37.879 60.317 40.000 Normal, Single 40, 128, 88 1, 4, 23
1280x720
18.000 24.000 59.400 Normal, Single 1760, 40, 220 5, 5, 20
37.500 50.000 74.250 Normal, Single 440, 40, 220 5, 5, 20
45.000 60.000 74.250 Normal, Single 110, 40, 220 5, 5, 20
1024x768 48.363 60.004 65.000 Normal, Single 24, 136, 160 3, 6, 29
1366x768
47.712 59.790 85.500 Single 70, 143, 213 3, 3, 24
48.000 60.000 72.000 14, 56, 64 1, 3, 28
1440x900
55.469 59.901 88.750 Normal, Single 48, 32, 80 3, 6, 17
55.935 59.887 106.500 Normal, Single 80, 152, 232 3, 6, 25
1280x1024 63.981 60.020 108.000 Normal, Single 48, 112, 248 1, 3, 38
1920x1080(I)
28.125 50.000 74.250 Normal, Single 528, 44, 148 4.5, 10, 30.5
31.250 50.000 72.000 32, 168, 184 45.5, 10, 114.5
33.750 60.000 74.250 Normal, Single 88, 44, 148 4.5, 10, 30.5
1920x1080
27.000 24.000 74.250 Normal, Single 638, 44, 148 4, 5, 36
56.250 50.000 148.500 Normal, Single 528, 44, 148 4, 5, 36
67.500 60.000 148.500 Normal, Single 88, 44, 148 4, 5, 36
2048x1080
66.576 59.924 147.000 Normal, Single 48, 32, 80 3, 10, 18
67.500 60.000 148.500 Normal, Single 44, 44, 64 4, 5, 36
2560x1080
26.400 24.000 99.000 Normal, Single 998, 44, 148 4, 5, 11
56.250 50.000 185.625 Normal, Single 548, 44, 148 4, 5, 36
66.636 59.978 181.250 48, 32, 80 3, 10, 18
66.000 60.000 198.000 Normal, Single 248, 44, 148 4, 5, 11
1920x1200
74.038 59.950 154.000 Normal, Single 48, 32, 80 3, 6, 26
74.556 59.885 193.250 Normal, Single 136, 200, 336 3, 6, 36
2048x1200
74.582 59.905 205.250 Normal, Single 136, 216, 352 3, 10, 32
74.100 60.000 157.684 8, 32, 40 21, 8, 6
2560x1440 88.787 59.951 241.500 Single 48, 32, 80 3, 5, 33
2560x1600 98.713 59.972 268.500 Normal, Single 48, 32, 80 3, 6, 37
3840x2160
52.593 23.993 266.750 216, 400, 616 3, 5, 24
52.438 23.999 209.750 48, 32, 80 3, 5, 17
54.000 24.000 297.000 Normal, Single 1276, 88, 296 8, 10, 72
56.250 25.000 297.000 Normal, Single 1056, 88, 296 8, 10, 72
67.500 30.000 297.000 Normal, Single 176, 88, 296 8, 10, 72
112.500 50.000 594.000 Normal* 3 , Single* 3 1056, 88, 296 8, 10, 72
135.000 60.000 594.000 Normal* 3 , Single* 3 176, 88, 296 8, 10, 72
4096x2160
52.561 23.979 284.250 224, 432, 656 3, 10, 19
52.397 23.980 223.000 48, 32, 80 3, 10, 12
54.000 24.000 297.000 Normal, Single 1020, 88, 296 8, 10, 72
56.250 25.000 297.000 Normal, Single 968, 88, 128 8, 10, 72
67.500 30.000 297.000 Normal, Single 88, 88, 128 8, 10, 72
112.500 50.000 594.000 Normal* 3 , Single* 3 968, 88, 128 8, 10, 72
135.000 60.000 594.000 Normal* 3 , Single* 3 88, 88, 128 8, 10, 72
FP : Front porch
SW : Sync width
BP : Back porch
