AEM DEBUG
This screen shows the binary data that is being sent between the AEM-2020 (Analog Expansion Module)
and the DGC-2020.
The AEM DEBUG screen is located on the front panel at SETTINGS > SYSTEM PARAMS > REMOTE
MODULE SETUP > AEM SETUP > AEM DEBUG MENU.
The following parameters are visible on the AEM DEBUG screen:
•
DGC TO AEM BP: DGC-2020 to AEM-2020 Binary Points. This is a 32-bit, bit packed number
representing the binary points transmitted from the DGC-2020 to the AEM-2020. Debug at this
level is not necessary.
•
AEM TO DGC BP: AEM-2020 to DGC-2020 Binary Points. This is a 32-bit, bit packed number
representing the binary points transmitted from the AEM-2020 to the DGC-2020. Debug at this
level is not necessary.
•
ANALOG INPUTS: For each analog input, the raw metered input value is displayed, and the
scaled metered input value. This is useful to check if the AEM-2020 is seeing a valid raw input
value (i.e. the raw 0 to 10 volt voltage input or 4 to 20 ma current input). The scaled value is the
raw input scaled up to the range specified by the Parameter Minimum and Parameter Maximum
value parameters in the Remote Analog Input settings.
•
THERMAL INPUTS: For each RTD input, the resistance in ohms measured by the RTD input is
displayed as well as the temperature calculated from the resistance measurement. For each
thermocouple input, the voltage in millivolts is displayed as well as the temperature calculated
from the resistance measurement.
