9400200990 Rev X DGC-2020 Modbus
™ Communication
B-127
Holding
Register
Parameter Range
Read/Write
Supported
Data
Format
Units
40298 Read Relay Image of both Main
and Aux Output individual bits
are 0 or 1 R Main is in lower byte and Aux is in
upper byte.
b0 = Aux Output 1,
b1 = Aux Output 2,
b2 = Aux Output 3,
b3 = Aux Output 4,
b4 = Aux Output 5,
b5 = Aux Output 6,
b6 = Aux Output 7,
b7 = Aux Output 8.
b8 = Master Start Relay,
b9 = Fuel Solenoid Relay,
b10 = PreHeat PreLube Relay,
b11 = Alarm Relay,
b12 = UNASSIGNED,
b13 = Buzzer On,
b14 = EPS Loaded Relay,
b15 = PreAlarm Relay,
40299 RESERVED
J1939 DIAGNOSTIC TROUBLE CODES
40300 Active DTC Number 16 – Lower
Two Bytes 0-65535 R Suppose the 32 bits of DTC Data is in
Register N and N+1.
SPN = (Register N: Most Significant 3
bits * 65536) + (Register N+1: LS Byte *
256) + (Register N+1: MS Byte)
FMI = Register N: Bits 8-12
Occurrence Count = Register N: Bits 0
through 6
40301 Active DTC Number 16 – Upper
Two Bytes 0-65535 R
40302 Active DTC Number 15 – Lower
Two Bytes 0-65535 R
40303 Active DTC Number 15 – Upper
Two Bytes 0-65535 R
40304 Active DTC Number 14 – Lower
Two Bytes 0-65535 R
40305 Active DTC Number 14 – Upper
Two Bytes 0-65535 R
40306 Active DTC Number 13 – Lower
Two Bytes 0-65535 R
40307 Active DTC Number 13 – Upper
Two Bytes 0-65535 R
40308 Active DTC Number 12 – Lower
Two Bytes 0-65535 R
40309 Active DTC Number 12 – Upper
Two Bytes 0-65535 R
40310 Active DTC Number 11 – Lower
Two Bytes 0-65535 R
40311 Active DTC Number 11 – Upper
Two Bytes 0-65535 R
40312 Active DTC Number 10 – Lower
Two Bytes 0-65535 R
40313 Active DTC Number 10 – Upper
Two Bytes 0-65535 R
40314 Active DTC Number 9 – Lower
Two Bytes 0-65535 R
40315 Active DTC Number 9 – Upper
Two Bytes 0-65535 R
40316 Active DTC Number 8 – Lower
Two Bytes 0-65535 R
40317 Active DTC Number 8 – Upper
Two Bytes 0-65535 R
40318 Active DTC Number 7 – Lower
Two Bytes 0-65535 R
40319 Active DTC Number 7 – Upper
Two Bytes 0-65535 R
40320 Active DTC Number 6 – Lower
Two Bytes 0-65535 R
40321 Active DTC Number 6 – Upper
Two Bytes 0-65535 R
