SPN
FMI
String Displayed
Description
601
#
CRUISE CNTL RESUME SW
Caption Indicating Cruise Control Resume Switch
602
#
CRUISE CNTL ACCEL SW
Caption Indicating Cruise Control Accelerate Switch
609
#
CONTROLLER #2
Caption Indicating Controller Number 2
611
#
SYS DIAGNST CODE 1
Caption Indicating System Diagnostic Code 1
611
3
Inj Short to PWR
Injector Wiring Shorted to Power
611
4
Inj Short to GND
Injector Wiring Shorted to Ground
620
#
5 VOLT SUPPLY
Caption Indicating 5 Volt Supply
623
#
RED STOP LAMP
Caption Indicating Red Stop Lamp
624
#
DIAGNOSTIC LAMP
Caption String for Diagnostic Lamp
624
#
COMBINED YELLOW
Caption Indicating a Yellow Alarm from the Engine ECU
625
#
PROP COMM NETWK 1
Caption Indicating Proprietary Communications Network 1
627
1
Inj Spply Vlt Problm
Injector Supply Voltage Problem
627
13
ECU ERROR
ECU Error
627
16
ECU Power Volt HI
ECU Power High Voltage
627
18
ECU Power Volt LO
ECU Power Low Voltage
628
#
PROGRAM MEMORY
Caption Indicating Program Memory
629
#
CONTROLLER #1
Caption Indicating Controller 1
630
#
ECU INTERNAL ERROR
Caption string for ECU Internal Error
630
#
ECU INTERNAL ERROR
Caption string for ECU Internal Error
636
#
ENG POSITION SENSOR
Caption Indicating Engine Position Sensor
636
2
Pump Pos Sns Noisy
Pump Position Sensor Input Noise
636
5
Pump Pos Sns Curr LO
Pump Position Sensor Current (Low)
636
6
Pump Pos Sns Curr HI
Pump Position Sensor Current (High)
636
8
Pump Pos Sns In MSNG
Pump Position Sensor Input Missing
636
10
Pump Pos Sns In ERR
Pump Position Sensor Input Pattern Error
637
2
Crank Pos Sns Noisy
Crank Position Input Noise
637
5
Crank Pos Sns Curr LO
Crank Position Sensor Current (Low)
637
6
Crank Pos Sns Curr HI
Crank Position Sensor Current (High)
637
7
Crnk/Pmp Pos Tmg OOS
Crank/Pump Position Timing Moderately Out of Sync
637
8
Crank Pos Sns MSNG
Crank Position Missing
637
10
Crank Pos Sns In ERR
Crank Position Input Pattern Error
639
#
J1939 NETWORK 1
Caption String for J1939 Network number 1
641
4
Trbo Actuator ERR
Turbo Actuator Error
641
12
ECU/Trbo Comm ERR
ECU/Turbo Communication Error
641
13
TrboAct Lrnd Val ERR
Turbo Actuator Learned Value Error
641
16
Trbo Act Temp MHI
Turbo Actuator Temp (Moderately High)
645
#
J1939 NETWORK 1
Caption String for J1939 Network number 1
651
#
CYLINDER 1 INJECTOR
Caption String for Cylinder 1 Injector
651
2
Cyl 1 EUI PN INVLD
Cylinder #1 EUI Part Number (Invalid)
651
5
Cyl 1 EUI Ckt OPEN
Cylinder #1 EUI Circuit (Open)
651
6
Cyl 1 EUI Ckt SHORT
Cylinder #1 EUI Circuit (Shorted)
651
7
Cyl 1 EUI Ckt MECH FL
Cylinder #1 EUI Circuit (Mechanical Failure)
651
13
Cyl 1 EUI QR INVLD
Cylinder #1 EUI Circuit QR Code (Invalid)
652
#
CYLINDER 2 INJECTOR
Caption String for Cylinder 2 Injector
652
2
Cyl 2 EUI PN INVLD
Cylinder #2 EUI Part Number (Invalid)
652
5
Cyl 2 EUI Ckt OPEN
Cylinder #2 EUI Circuit (Open)
652
6
Cyl 2 EUI Ckt SHORT
Cylinder #2 EUI Circuit (Shorted)
652
7
Cyl 2 EUI Ckt MECH FL
Cylinder #2 EUI Circuit (Mechanical Failure)
652
13
Cyl 2 EUI QR INVLD
Cylinder #2 EUI Circuit QR Code (Invalid)
653
#
CYLINDER 3 INJECTOR
Caption String for Cylinder 3 Injector
653
2
Cyl 3 EUI PN INVLD
Cylinder #3 EUI Part Number (Invalid)
653
5
Cyl 3 EUI Ckt OPEN
Cylinder #3 EUI Circuit (Open)
653
6
Cyl 3 EUI Ckt SHORT
Cylinder #3 EUI Circuit (Shorted)
