B-136 DGC-2020 Modbus
™ Communication
9400200990 Rev X
Holding
Register
Parameter Range
Read/Write
Supported
Data
Format
Units
40761 MTU Pre-alarms 0-65535 R b0 = High ECU Temp,
b1 = High Oil Temp,
b2 = High Intercooler Temp,
b3 = High Charge Air Temp,
b4 = High Coolant Temp,
b5 = Shutdown Override,
b6 = High Fuel Rail Press,
b7 = Low Fuel Rail Press,
b8 = Low Coolant Level,
b9 = Low Charge Air Pressure,
b10 = Low Fuel Deliv Pressure,
b11 = Low Oil Pressure,
b12 = Combined Yellow,
b13-b15 UNASSIGNED
Legacy Parameter Table for DGC-2000
The DGC-2020 maps all legacy parameters previously associated with the DGC-2000 into the Holding
Register address space (40000 to 41999). Some of these registers overlap the registers of the DGC-500
and DGC-1000 which constitutes a separate register table. Query address N will access the Holding
Register N+1. The Data Format is Integer type data unless identified otherwise in the Data Format
column.
Holding
Register
Parameter Range
Read/Write
Supported
Data
Format
Units
PRODUCT ACCESS INFORMATION
40252 <Reserved>
40253 User Ltd Access Password(a) ‘A’-’Z’, ‘a’-’z’, ‘_’, ‘0’ - ’9’ - W
40254 User Ltd Access Password(b) - W
40255 User Ltd Access Password(c) - W
40256 User Ltd Access Password(d) - W
40257 <Reserved>
40006 Front Panel Password(a) All front panel pushbuttons
except for RUN, OFF,
AUTO R -
40007 Front Panel Password(b) R -
40008 Front Panel Password(c) R -
40009 Front Panel Password(d) R -
40010 <Reserved>
40011 <Reserved>
40012 <Reserved>
40013 <Reserved>
40014 User Ttl Access Password(a) ‘A’-’Z’, ‘a’-’z’, ‘_’, ‘0’-’9’ - W
40015 User Ttl Access Password(b) - W
40016 User Ttl Access Password(c) - W
40017 User Ttl Access Password(d) - W
40030 <Reserved>
40031 Logoff Data=Don’t Care - W
40032 <Reserved>
COMMUNICATION PARAMETERS
40051 Comm Baud Rate 0 R W 0 =9600 Baud
