9400200990 Rev X
DGC-2020 Modbus
™ Communication
B-55
Register
Description
Type
Units
Scaling
Factor
R/W
Range
45042
ECU Oil Pressure
Uint32
4 kPa/bit gain, 0
kPa offset
N/A
R
0 to +1000 kPa
45044
ECU Coolant Pressure
Uint32
2 kPa/bit gain, 0
kPa offset
N/A
R
0 to +500 kPa
45046
ECU Coolant Level
Uint32
0.4 %/bit gain, 0 %
offset
N/A
R
0 to +100 %
45048
ECU Fuel Rate
Uint32
0.05 L/h per bit , 0
offset
N/A
R
0 to +3212.75 L/h
45050
ECU Barometric
Pressure
Uint32
0.5 kPa/bit gain, 0
kPa offset
N/A
R
0 to +125 kPa
45052
ECU Ambient Air
Temperature
Uint32
0.03125 °C/bit gain,
-273 °C offset
N/A
R
-273 to +1735.0 °C
45054
ECU Air Inlet
Temperature
Uint32
1 °C/bit gain, -40 °C
offset
N/A
R
-40 to +210 °C
45056
ECU Boost Pressure
Uint32
2 kPa/bit gain, 0
kPa offset
N/A
R
0 to +500 kPa
45058
ECU Intake Manifold
Temperature
Uint32
1 °C/bit gain, -40 °C
offset
N/A
R
-40 to +210 °C
45060
ECU Air Filter
Differential Pressure
Uint32
0.05 kPa/bit gain, 0
kPa offset
N/A
R
0 to +12.5 kPa
45062
ECU Exhaust Gas
Temperature
Uint32
0.03125 °C/bit gain,
-273 °C offset
N/A
R
-273 to +1735.0 °C
45064
ECU Electrical Potential
Voltage
Uint32
0.05 V/bit gain, 0 V
offset
N/A
R
0 to +3212.75 V
45066
ECU Battery Potential
Voltage Switched
Uint32
0.05 V/bit gain, 0 V
offset
N/A
R
0 to +3212.75 V
45068
ECU Speed at Idle Point
1
Uint32
0.125 rpm/bit, 0 rpm
offset
N/A
R
0 to 8031.875 rpm
45070
ECU Torque at Idle
Point 1
Uint32
1%/bit gain, -125%
offset
N/A
R
0 to +125 %
45072
ECU Speed at Idle Point
2
Uint32
0.125 rpm/bit, 0 rpm
offset
N/A
R
0 to 8031.875 rpm
45074
ECU Torque at Idle
Point 2
Uint32
1%/bit gain, -125%
offset
N/A
R
0 to +125 %
45076
ECU Speed at Idle Point
3
Uint32
0.125 rpm/bit, 0 rpm
offset
N/A
R
0 to 8031.875 rpm
45078
ECU Torque at Idle
Point 3
Uint32
1%/bit gain, -125%
offset
N/A
R
0 to +125 %
45080
ECU Speed at Idle Point
4
Uint32
0.125 rpm/bit, 0 rpm
offset
N/A
R
0 to 8031.875 rpm
45082
ECU Torque at Idle
Point 4
Uint32
1%/bit gain, -125%
offset
N/A
R
0 to +125 %
45084
ECU Speed at Idle Point
5
Uint32
0.125 rpm/bit, 0 rpm
offset
N/A
R
0 to 8031.875 rpm
45086
ECU Torque at Idle
Point 5
Uint32
1%/bit gain, -125%
offset
N/A
R
0 to +125 %
45088
ECU Speed at High Idle
Point 6
Uint32
0.125 rpm/bit, 0 rpm
offset
N/A
R
0 to 8031.875 rpm
45090
ECU Gain of End Speed
Governor
Uint32
0.0007813%ref
trq/rpm per bit gain,
0 Offset
N/A
R
0 to 50.2 %/rpm
45092
ECU Reference Engine
Torque
Uint32
1 Nm/bit gain, 0 Nm
offset
N/A
R
0 to 64 255 Nm
45094
ECU Override Speed
Point 7
Uint32
0.125 rpm/bit, 0 rpm
offset
N/A
R
0 to 8031.875 rpm
45096
ECU Override Time
Limit
Uint32
0.1 s/bit gain, 0 s
offset
N/A
R
0 s to 25 s
45098
ECU Speed Lower Limit
Uint32
10 rpm/bit gain, 0
rpm offset
N/A
R
0 to 2500 rpm
45100
ECU Speed Upper Limit
Uint32
10 rpm/bit gain, 0
rpm offset
N/A
R
0 to 2500 rpm
45102
ECU Torque Lower
Limit
Uint32
1%/bit gain, -125%
offset
N/A
R
0 to 125%
45104
ECU Torque Upper
Limit
Uint32
1%/bit gain, -125%
offset
N/A
R
0 to 125%
