Basler Electric DGC-2020 - Manual (Page 505)

9400200990 Rev X DGC-2020 Modbus
™ Communication
B-73
Register Description Type Units
Scaling
Factor
R/W Range
45584-85 Logic Control Relay
Status Uint32 N/A N/A R Bit 0 = Not Used
Bit 1 = Not Used
Bit 2 = Not Used
Bit 3 = Not Used
Bit 4 = Not Used
Bit 5 = Not Used
Bit 6 = Not Used
Bit 7 = Not Used
Bit 8 = Not Used
Bit 9 = Not Used
Bit 10 = Not Used
Bit 11 = Not Used
Bit 12 = Not Used
Bit 13 = Not Used
Bit 14 = Not Used
Bit 15 = Not Used
Bit 16 = Logic Control Relay 16
Bit 17 = Logic Control Relay 15
Bit 18 = Logic Control Relay 14
Bit 19 = Logic Control Relay 13
Bit 20 = Logic Control Relay 12
Bit 21 = Logic Control Relay 11
Bit 22 = Logic Control Relay 10
Bit 23 = Logic Control Relay 9
Bit 24 = Logic Control Relay 8
Bit 25 = Logic Control Relay 7
Bit 26 = Logic Control Relay 6
Bit 27 = Logic Control Relay 5
Bit 28 = Logic Control Relay 4
Bit 29 = Logic Control Relay 3
Bit 30 = Logic Control Relay 2
Bit 31 = Logic Control Relay 1
45586-87 I/O Modules Connected Uint32 N/A N/A R Bit 0 = Not Used
Bit 1 = Not Used
Bit 2 = Not Used
Bit 3 = Not Used
Bit 4 = Not Used
Bit 5 = Not Used
Bit 6 = Not Used
Bit 7 = Not Used
Bit 8 = Not Used
Bit 9 = Not Used
Bit 10 = Not Used
Bit 11 = Not Used
Bit 12 = Not Used
Bit 13 = Not Used
Bit 14 = Not Used
Bit 15 = Not Used
Bit 16 = Not Used
Bit 17 = Not Used
Bit 18 = Not Used
Bit 19 = Not Used
Bit 20 = Not Used
Bit 21 = Not Used
Bit 22 = Not Used
Bit 23 = Not Used
Bit 24 = Not Used
Bit 25 = Not Used
Bit 26 = Not Used
Bit 27 = Not Used
Bit 28 = Not Used
Bit 29 = AEM Connected
Bit 30 = CEM Connected
Bit 31 = LSM Connected
45588 Max Vector Shift Int32 N/A Centi R 0 - 100000
45590 Max DF/DT Int32 N/A Centi R 0 - 100000
