B-34
DGC-2020 Modbus
™ Communication
9400200990 Rev X
Register
Description
Type
Units
Scaling Factor
R/W
Range
44608
Engine Overload 2 Pre-Alarm
1 Phase Threshold
Int32
Percent
N/A
RW
0 - 200
44610
Engine Overload 2 Pre-Alarm
1 Phase Hysteresis
Int32
Percent
N/A
RW
1 - 10
44612
Engine Overload 2 Pre-Alarm
1 Phase Low Line Scale Factor
Float
N/A
N/A
RW
0.001 - 3
44614
Engine Overload 3 Pre-Alarm
Enable
Int32
N/A
N/A
RW
0 = Disable
1 = Enable
44616
Engine Overload 3 Pre-Alarm
3 Phase Threshold
Int32
Percent
N/A
RW
0 - 200
44618
Engine Overload 3 Pre-Alarm
3 Phase Hysteresis
Int32
Percent
N/A
RW
1 - 10
44620
Engine Overload 3 Pre-Alarm
1 Phase Threshold
Int32
Percent
N/A
RW
0 - 200
44622
Engine Overload 3 Pre-Alarm
1 Phase Hysteresis
Int32
Percent
N/A
RW
1 - 10
44624
Engine Overload 3 Pre-Alarm
1 Phase Low Line Scale Factor
Float
N/A
N/A
RW
0.001 - 3
44626
LSM Comm Failure Pre-alarm
Enable
Int32
N/A
N/A
RW
0 = Disable
1 = Enable
44628
Intergenset Comm Failure Pre-
alarm Enable
Int32
N/A
N/A
RW
0 = Disable
1 = Enable
44630
AVR Bias Output Limit Pre-
alarm Activation Delay
Int32
Second
N/A
RW
1 - 15
44632
AVR Bias Output Limit Pre-
alarm Enable
Int32
N/A
N/A
RW
0 = Disable
1 = Enable
44634
GOV Bias Output Limit Pre-
alarm Activation Delay
Int32
Second
N/A
RW
1 - 15
44636
GOV Bias Output Limit Pre-
alarm Enable
Int32
N/A
N/A
RW
0 = Disable
1 = Enable
44638
ID Missing Pre-alarm Enable
Int32
N/A
N/A
RW
0 = Disable
1 = Enable
44640
ID Repeat Pre-alarm Enable
Int32
N/A
N/A
RW
0 = Disable
1 = Enable
44642
CEM Comm Failure Pre-alarm
Enable
Int32
N/A
N/A
RW
0 = Disable
1 = Enable
44644
AEM Comm Failure Pre-alarm
Enable
Int32
N/A
N/A
RW
0 = Disable
1 = Enable
44646
Checksum Failure Pre-alarm
Enable
Int32
N/A
N/A
RW
0 = Disable
1 = Enable
44648
Low Oil Pressure Alarm (metric
pressure units is Bar)
Int32
Bar
Deci
RW
2 - 103
44650
Low Oil Pressure Pre-Alarm
(metric pressure units is Bar)
Int32
Bar
Deci
RW
2 - 103
44652
Sync Fail Pre-alarm Enable
Int32
N/A
N/A
RW
0 = Disable
1 = Enable
44654
Breaker Close Fail Pre-Alarm
Enable
Int32
N/A
N/A
RW
0 = Disable
1 = Enable
44656
Breaker Open Fail Pre-Alarm
Enable
Int32
N/A
N/A
RW
0 = Disable
1 = Enable
44658
Breaker Close Fail Pre-Alarm
Monitor
Int32
N/A
N/A
RW
0 = Transitions Only
1 = Always
44660
Breaker Open Fail Pre-Alarm
Monitor
Int32
N/A
N/A
RW
0 = Transitions Only
1 = Always
44662
Reverse Rotation Pre-Alarm
Enable
Uint32
N/A
N/A
RW
0 = Disable
1 = Enable
44664-748
FUTURE USE
Metering
Register
Description
Type
Units
Scaling
Factor
R/W
Range
44750
Gen VAB Metering
Int32
Volt
N/A
R
(-2147483648) - 2147483647
44752
Gen VBC Metering
Int32
Volt
N/A
R
(-2147483648) - 2147483647
44754
Gen VCA Metering
Int32
Volt
N/A
R
(-2147483648) - 2147483647
