Table 3-2. Engine Configuration Parameters Obtained from CAN bus Interface
ECU Parameter Metric Units English Units Update Rate
∗
SPN
Engine Speed at High Idle Point 6 rpm rpm 5 s 532
Engine Speed at Idle Point 1 rpm rpm 5 s 188
Engine Speed at Point 2 rpm rpm 5 s 528
Engine Speed at Point 3 rpm rpm 5 s 529
Engine Speed at Point 4 rpm rpm 5 s 530
Engine Speed at Point 5 rpm rpm 5 s 531
Gain (Kp) of End Speed Governor %/rpm %/rpm 5 s 545
Maximum Momentary Engine Override Speed Point 7 rpm rpm 5 s 533
Maximum Momentary Engine Override Time Limit seconds seconds 5 s 534
Percent Torque at Idle Point 1 % % 5 s 539
Percent Torque at Point 2 % % 5 s 540
Percent Torque at Point 3 % % 5 s 541
Percent Torque at Point 4 % % 5 s 542
Percent Torque at Point 5 % % 5 s 543
Reference Engine Torque N
•m ft-lb 5 s 544
Requested Speed Control Range Lower Limit rpm rpm 5 s 535
Requested Speed Control Range Upper Limit rpm rpm 5 s 536
Requested Torque Control Range Lower Limit % % 5 s 537
Requested Torque Control Range Upper Limit % % 5 s 538
∗ SPN is suspect parameter number.
CAUTION
When the CAN bus is enabled, the DGC-2020 will ignore the following sender
inputs: oil pressure, coolant temperature, and magnetic pickup.
Under certain circumstances, the following strings may be displayed on the front panel HMI and in the
Metering Explorer of BESTCOMSPlus
®:
•
NC (Not Connected) - String displayed for a J1939 parameter when the engine ECU is not
connected to the DGC-2020.
•
SF (Sender Fail) - String displayed for a J1939 parameter when the engine ECU sends a special
code indicating a measurement failure for the parameter. For example, if oil sender is determined
to be bad by the ECU, it sends a special code in place of the J1939 oil pressure data indicating a
sender fail condition.
•
NS (Not Sent) - String displayed for a J1939 parameter when the J1939 parameter has not been
sent to the DGC-2020 by the engine ECU.
•
NA (Not Applicable) - String displayed for a J1939 parameter when the engine ECU sends a
special code for the parameter indicating that the parameter is not implemented or not applicable
in the ECU.
•
UF (Unknown Failure) - String displayed when the J1939 parameter data received by the ECU is
not within the valid J1939 data range for the parameter but is not one of the special codes above.
Table 3-3 lists the J1939 data transmitted from the DGC-2020.
Table 3-3. J1939 Data Transmitted from the DGC-2020
ECU Parameter Update Rate
∗
SPN
Battle Override Switch 100 ms 1237
Speed Request 10 ms 518
9400200990 Rev X DGC-2020 Functional Description 3-7
