9400200990 Rev X
DGC-2020 Modbus
™ Communication
B-41
Register
Description
Type
Units
Scaling
Factor
R/W
Range
44832-33
Status Metering 1
Int32
N/A
N/A
R
Bit 0 = Idle Request
Bit 1 = Lamp Test
Bit 2 = Alarm Silence
Bit 3 = Reset
Bit 4 = Alternate Frequency
Override
Bit 5 = Start Delay Bypass
Bit 6 = Cooldown and Stop
Request from Logic
Bit 7 = Cooldown Request from
Logic
Bit 8 = External Start Delay
Bit 9 = Off Mode Cooldown
Bit 10 = PF Mode Active
Bit 11 = Var Mode Active
Bit 12 = Cooldown Timer Active
Bit 13 = Engine Running
Bit 14 = Fuel Leak Detect
Bit 15 = Battery Charger Failure
Bit 16 = Low Coolant Level
Bit 17 = Gen Failed
Bit 18 = Gen Stable
Bit 19 = Gen Dead
Bit 20 = Bus Failed
Bit 21 = Bus Stable
Bit 22 = Bus Dead
Bit 23 = Gen Breaker Closed
Bit 24 = Mains Breaker Closed
Bit 25 = Grounded Delta Override
Bit 26 = Battle Override
Bit 27 = Auto Transfer Switch
Bit 28 = Low Line Override
Bit 29 = Single Phase AC Override
Bit 30 = Single Phase Override
Bit 31 = EPS Supplying Load
44834
Hours Until
Maintenance
Int32
N/A
N/A
RW
0 - 5000
44836
Cum. Total Engine Run
Hrs.
Int32
Hour
N/A
R
0 - 99999
44838
Cum. Total Engine Run
Min.
Int32
N/A
N/A
R
0 - 59
44840
Cum. Loaded Engine
Run Hrs.
Int32
N/A
N/A
R
0 - 99999
44842
Cum. Loaded Engine
Run Min.
Int32
N/A
N/A
R
0 - 59
44844
Cum. Unloaded Engine
Run Hrs.
Int32
Hour
N/A
R
0 - 99999
44846
Cum. Unloaded Engine
Run Min.
Int32
N/A
N/A
R
0 - 59
44848
Cum. Total kW-Hrs
Uint32
KiloWattHour
N/A
R
0 - 999999999
44850
Cum. Total kW-Mins
Uint32
KiloWattMinute
N/A
R
0 - 4294967295
44852
Commission Date
Month
Uint32
N/A
N/A
RW
1 - 12
44854
Commission Date Day
Uint32
N/A
N/A
RW
1 - 31
44856
Commission Date Year
Uint32
N/A
N/A
RW
0 - 99
44858
Session Total Engine
Run Hrs.
Int32
Hour
N/A
R
0 - 99999
44860
Session Total Engine
Run Min.
Int32
N/A
N/A
R
0 - 59
44862
Session Loaded Engine
Run Hrs.
Int32
Hour
N/A
R
0 - 99999
44864
Session Loaded Engine
Run Min.
Int32
N/A
N/A
R
0 - 59
44866
Session Unloaded
Engine Run Hrs.
Int32
Hour
N/A
R
0 - 99999
