■ INTRCOOLR TMP
■ INTCLR LMT HI
● STATUS
○ AUTO XFER SWITCH (Visible when the Auto Transfer Switch programmable function is configured to
be driven by an input.)
○ EPS SUPP. LOAD
○ GEN BREAKER
○ MAINS BREAKER
○ BATTLE OVERRIDE (Visible when the Battle Override programmable function is configured to be
driven by an input.)
○ LOW LINE OVERRIDE (Visible when the Low Line Override programmable function is configured to be
driven by an input.)
○ LOW COOL LEVEL (Visible when the Low Coolant Level programmable function is configured to be
driven by an input.)
○ BATT CHRG FAIL (Visible when the Battery Charger Fail programmable function is configured to be
driven by an input.)
○ FUEL LEAK DETECT (Visible when the Fuel Leak Detect programmable function is configured to be
driven by an input.)
○ GRND DELTA O-RIDE (Visible when Generator Connection is configured for Delta and the Grounded
Delta Override programmable function is configured to be driven by an input.)
○ 1 PHASE O-RIDE (Visible when the 1-Phase Override programmable function is configured to be driven
by an input.)
○ 1 PHASE AC O-RIDE (Visible when the 1-Phase AC Override programmable function is configured to
be driven by an input.)
○ BUS DEAD
○ BUS STABLE
○ BUS FAILED
○ BUS FWD ROT
○ BUS REV ROT
○ GEN DEAD
○ GEN STABLE
○ GEN FAILED
○ GEN FWD ROT
○ GEN REV ROT
○ ENG RUNNING
○ CLDN TMR ACTVE
○ OFF MODE COOLDN
○ COOLDN REQ
○ COOL & STOP REQ
○ var MODE
○ PF MODE
○ EXT START DEL
○ START DEL BYPASS
○ ALT FRQ O-RIDE
○ RESET
○ ALARM SILENCE
○ LAMP TEST
○ IDLE REQUEST
○ LOAD TAKEOVER
○ MAINS FAIL TEST
○ SYNCHRONIZING
○ SYNC VOLT OK
○ SYNC SLIP FRQ OK
○ SYNC ANGLE OK
○ SYNC BRK CL OK
○ PARALLEL TO MAINS
○ LSM CONNECTED
○ CEM CONNECTED
○ AEM CONNECTED
● INPUTS
○ INPUT X (X = 1 to 16 (17 to 26 optional))
● OUTPUTS
○ START
○ RUN
○ PRESTART
○ OUTPUT X (X = 1 to 12 (13 to 36 optional))
